ML2.5-60-35 IgniteNet MetroLinq 2.5G 60 PtP Radio
ML2.5-60-35 IgniteNet MetroLinq 2.5G 60 PtP Radio

ML2.5-60-35 IgniteNet MetroLinq 2.5G 60 PtP Radio

ML2.5-60-35
In Stock
$970.00
Tax included

ML2.5-60-35

The ML2.5-60-35 from IgniteNet is a powerful point-to-point 60GHz radio enabling high performing, interference-free network connection with up to 2.5 Gbps aggregate throughput. The MetroLink 2.5G 60 features a hybrid metal and plastic design built to withstand environments with harsh temperatures, precipitation and humidity. This device features (1) 2.5 Gigabit Ethernet port, (2) SFP port, (1) USB 3.0 port, and an internal 5GHz radio which can configured as a backup to provide automatic failover during adverse conditions when 60GHz wireless is not available.

Supported point-to-point distance: 1.6km (1 mile)

Related Products & Accessories



Product Features:

  • Inteference-Free & Unlicensed Band The IgniteNet MetroLinq 60 offers unprecedented performance – combining both the benefits of unlicensed band operation with no interfer
  • Dual Band 60GHz & 5GHz OperaTonence! The MetroLinq 60 includes a second 5GHz radio which can be configured as a backup to the 60GHz to provide automatic failover during adverse conditions. This allows links to be extended further without effecting link availability.
  • Robust Weather-Resistant Design The MetroLinq 60 features a hybrid metal/plastic design built to withstand the harshest environments including precipitation, hot/cold weather and high/low humidities.
  • Powerful, Flexible ConfiguraTon The MetroLinq 60 can operate either as a standalone device or as a coordinated, cloud-managed device, easily meeting the requirements of any installation.

ML2.5-60-35 Features:

  • 2.5+Gbps Aggregate throughput; dynamically allocated (60GHz)
  • Management VLAN support and VLAN pass-through
  • Support Service Provider and Enterprise type networks
  • Stand-alone or Cloud-controlled operating modes
  • Link failover/backup (60GHz + 5GHz) per client
  • 128bit AES Encryption (standard; 5GHz and 60GHz)
  • SNMP Monitoring with Private MIB

Product Applications:

  • Fixed Wireless Access (broadband)
  • 3G/4G Backhaul
  • Metro WiFi
  • Campus Interconnection
  • Hybrid Fiber/Wireless Networks

Product Specifications :

  • (1) 2.5 Gigabit Ethernet Port (PoE IN 24-48V)
  • (1) SFP Port
  • (1) Screw Terminal Block (DC Power IN 24-48V)
  • (1) USB 3.0 Port
  • Dual flash image support
  • LEDs: Power, Ethernet, Wireless, Health/Status
  • Dimensions: 350 x 350 x 220mm
  • Power: 24-48V/1.5A passive Gigabit PoE or DC
  • Operating Temperature: -40 to 70°C
  • Storage Temperature: -40 to 70°C
  • Operating Humidity: 10 to 90% non-condensing (RH)
  • RF Performance (TX):
    60GHz: 14dBm @ 2.5Gbps
  • 5GHz: 27dBm @ 6Mbps, 23dBm @ 866Mbps
  • RF Performance (RX):
    60GHz: -74dBm @ MCS1; -60dBm @ MCS9
    5GHz: -94dBm @ MCS0; -72dBm @ MCS15

Device Type
PTP/PTMP Radio
Device Features
Outdoor
Wireless System
5GHz
60GHz
SFP
Yes, 1G SFP
Ethernet Ports
1 Eth port
Link-Distance
over 1 Kms
4712331715180
