AVIOSYS IP Power 9258 4-Port Web Managed Remote Power Controller PING version

IP9258 - AVIOSYS IP Power 9258 4-Port Web Managed Remote Power Controller

IP POWER 9258S has built in web controller which provide the control of the power outlets. With the remote network control technology, user can control or query the power supply of equipment. It is also SNMP compatible (monitoring).

User can remotely control the power switch with any computer connected to the LAN segment.
There is also Android application available

Mechanical & Outlook of IP9258S:

• EC 320 Connector design, 1 of Male type Inlet (power in), 4 of Female type Outlet (Power output switch via Ethernet)
• Installs with standard PC power cords.
• Total power control up to 10A/120VAC, 10A/240VAC, 7A/250VAC.
• 1 of AC Power rocker switch with light .
• 4 LED power switch status indicator.8
• 1 RJ45 for Ethernet control.
• 1 RS232 for UART control
• Dimension 220mmx120mmX45mm,Metal CASE design, 9. Operating Temperature: 0°C to 55°C; Controller dissipates 5 watts max.

Network functions:

• Built-in web server
• Support HTTP and DHCP/IP protocol. Windows SDK available, Telnet.
• Security password identify to be sure system stability .
• Online update firmware available if necessary.
• SNMP functionality
• PING watchdog
