    EMP-8603 High Power Atheros 6thG miniPCI module



    Engenius EMP-8603 Premium radio module performs extreme high power and economizes the power consumption on the system platform. It supports Atheros Turbo mode with high-speed wireless connection with data rate up to 108Mbps. EMP-8603 Premium is mini-PCI types A module, supports dual-band (2.4GHz & 5GHz) high transmit output power up to 500mW in 5GHz and 800mW in 2.4GHz. For outstanding performance on the extremely output power, it enables the longer transmit distance & provides the wider bandwidth & backhaul for 5GHz.

    EMP-8603 High Power Atheros 6thG miniPCI module



    Engenius EMP-8603 Premium radio module performs extreme high power and economizes the power consumption on the system platform. It supports Atheros Turbo mode with high-speed wireless connection with data rate up to 108Mbps. EMP-8603 Premium is mini-PCI types A module, supports dual-band (2.4GHz & 5GHz) high transmit output power up to 500mW in 5GHz and 800mW in 2.4GHz. For outstanding performance on the extremely output power, it enables the longer transmit distance & provides the wider bandwidth & backhaul for 5GHz.

    With enhanced features on the ESD protection, industrial-based operating temperature, economized system power consumption, industrial-best sensitivity than normal module, MMCX connectors, and stable heating protection design, makes the module is easily to integrate into a wide range of any platform.


    Features of EMP-8603:

    Features

    Benefits

    500mW output power in 5GHz

    Wider bandwidth & backhaul for 5GHz

    800mW output power in 11b, and 600mW in 11g

    Improve high and successful transmit range

    Turbo mode support

    Supports Super A/G up to 108Mbps data rate

    Industrial-best sensitivity

    -94 dBm @ 6 Mbps  ,  -74 dBm @ 54 Mbps

    Advanced power consumption management

    Effectively reduce the total power consumption on the platform up to 3.5W

    Improving the heat issue

    MTBF reliability improvement and keeps the system free from heat issue

    ESD protection up to 16 kV

    Make the module & platform more reliable and stable

    Industrial-based operating temperature

    Extended operating temperature -40~+85C

    MMCX antenna connectors

    Two MMCX connectors (One is for 2.4GHz, and the other is for 5GHz)

    5/10/20 Channel bandwidth support

    It’s optional for special request, makes your RF management more flexible

    Device Type
    mini PCI Card
    Wireless System
    5GHz, 2.4GHz
