3G GPS/GSM Multi-Band Antenna with magnetic base

    Multi Band 3G GPS/GSM Antenna

    ANT-GPS/GSM
    Available
    A$31.00
    Tax included

    Multi-Band Antenna GPS/GSM/HSDPA (3G)

    This multiband (GPS/GSM) antenna with 3m of RG174 cable and SMA male connectors is a perfect addon to any istallations that requires accurate positioning via GPS systems and connects to the Internet via the GSM networks, ie 3G. Embrasing RB411UAHR with this antenna will create an excellent combo when it comes to the fully featured wireless router with the GPS positioning (additional GPS card is required)

    Multi-Band Antenna GPS/GSM/HSDPA (3G)

    This multiband (GPS/GSM) antenna with 3m of RG174 cable and SMA male connectors is a perfect addon to any istallations that requires accurate positioning via GPS systems and connects to the Internet via the GSM networks, ie 3G. Embrasing RB411UAHR with this antenna will create an excellent combo when it comes to the fully featured wireless router with the GPS positioning (additional GPS card is required)

    Multi band antenna overview:

    Dielectric Antenna
    • Center Frequency(MHz):1575.42±3
    • VSWR:1.5:1
    • Bandwidth(MHz):±5
    • Impedance(Ω):50
    • Peak Gain >3dBi Based on 7cm×7cm ground plane
    • Gain Coverage >-4dBi at –90°<0 <+90°(over 75% Volume)
    • Polarization:RHCP (Right Hand Circular Polarization)

    GSM Antenna
    • Center Frequency(MHz):850/900/1800/1900/2100
    • VSWR:2.0:1
    • Impedance (Ω):50
      • Typical Gain:2dBi+/-1dBi@850MHz ; 2dBi+/-1dBi@900MHz
      •                           1dBi+/-1dBi@1800MHz;1dBi+/-1dBi@1900MHz/2100MHZ

    LNA/Filter
    • LNA Gain(Without Cable) :28 dBi Typical
    • Noise Figure(dB):1.5
    • Filter Out Band Attenuation (f0=1575.42 MHz)
    • 7dB Min f0+/-20MHz ;
    • 20dB Min f0+/-50MHz;
    • 30dB Min f0+/-100MHz
    • VSWR <2.0
    • DC Voltage(V):2.7/3.0/3.3/5.0
    • DC Current(mA):11 Max
    Mechanical
    • Weight(gram)<130
    • Size(mm):70×70×14
    • Cable GPS(m):RG174
    •             GSM(m):RG174
    •             length: 3m (both)
    • Connector GPS:Male-SMA
    •                     GSM:Male-SMA
    • Mounting:Magnetic
    • Housing:Black
    Environmental
    • Working Temp:-40℃~+85℃
    • Storage Temp:-45℃~+100℃
    • Vibration:Sine sweep 1g(0-p)10~50~10Hz each axis
    • Humidity:95%~100%RH
    • Weatherproof:Yes
    Device Type
    Antenna
